Plot a Variable as a Time Series — plot

Plots one or more numeric variables from an aniframe against time, with one line per trajectory group (every variables_what column and every non-time variables_when column in the metadata). Use it for any per-frame measure — speed, acceleration, a confidence score, a temperature channel, or any other derived column.

Usage

plot_timeseries(data, ...)

# Default S3 method
plot_timeseries(
  data,
  variable = NULL,
  ...,
  layout = c("inline", "facet"),
  mode = c("light", "dark"),
  palette = "Dark 3"
)

Arguments

data: An aniframe object.
...: Additional arguments (currently unused).
variable: Name(s) of the column(s) to plot on the y axis — a character vector. Required (no auto-detection). Several names draw a stacked panel per variable.
layout: Either "inline" (default, all groups in one panel) or "facet" (one panel per group).
mode: Either "light" (default) or "dark"; passed to theme_animovement().
palette: Name of a qualitative palette accepted by grDevices::hcl.colors(); controls the hue family across groups.

Value

A ggplot object for a single variable, or a stacked patchwork for several.

Details

Pass several names to variable to draw a panel per variable, vertically stacked with a shared x axis and a single shared legend (via plots()); stacking makes it easy to compare their shape over time. A single variable returns a plain ggplot.

The layout argument chooses how groups are arranged, mirroring plot_events():

"inline" (default): all groups share one panel as coloured lines, with a legend when there is more than one group.
"facet": each group gets its own panel — facet_grid() when both an identity and a (non-time) condition vary, otherwise facet_wrap() with the panels stacked in rows so the shared x axis lines up.

Colours come from palette_animovement(), matching plot_trajectory(). The x axis uses the same time-unit handling as plot_events() — HH:MM:SS for true time units, raw frames otherwise.
