library(animovement)
#> -- Attaching packages ------------------------------------- animovement 0.7.3 --
#> v aniframe 0.6.0 v anicheck 0.2.0
#> v aniread 0.5.0 v animetric 0.3.2
#> v anispace 0.1.3 v anivis 0.2.0
#> v aniprocess 0.2.0
library(tibble)
library(ggplot2)
library(tidyr)
#>
#> Attaching package: 'tidyr'
#> The following object is masked from 'package:aniprocess':
#>
#> replace_na
library(dplyr, warn.conflicts = FALSE)
library(here)
#> here() starts at /home/runner/work/animovement/animovement
here::i_am("vignettes/articles/calculate-kinematics.Rmd")
#> here() starts at /home/runner/work/animovement/animovementCalculate kinematics
When we work with movement data, we are often interested in more than
just where an animal is; we’re interested in how fast it moves,
where it is heading etc. calculate_kinematics calculates a
range of kinematic variables:
-
distance: The distance the animal moved since the last observation (simply calculated using Pythagoras’ theorem) -
v_translation: The translational velocity, like what you see on a speedometer in a car. -
direction: The direction (in radians) the animal is heading - where the arrow on the compass is heading. -
rotation: Difference from direction of the last observation. -
v_rotation: The rotational velocity (in rad/s).
# Augment all data in list
df_kinematics <- df_smooth |>
calculate_kinematics()
glimpse(df_kinematics)
#> Rows: 19
#> Columns: 17
#> Sampling rate: 60 Hz
#> Time: 2023-09-14 14:37:55.977 to 2023-09-14 14:37:56.277
#> $ keypoint <fct> centroid, centroid, centroid, centroid, centroid,…
#> $ time <dbl> 0.00000000, 0.01666667, 0.03333333, 0.05000000, 0…
#> $ x <dbl> NA, 0.005076142, 0.011421320, 0.016497462, 0.0203…
#> $ y <dbl> NA, 0.005076142, 0.011421320, 0.016497462, 0.0203…
#> $ speed <dbl> NA, NA, 0.4845656, 0.3768843, 0.2692031, 0.215362…
#> $ acceleration <dbl> NA, NA, NA, -6.460874e+00, -4.845656e+00, -1.6152…
#> $ path_length <dbl> 0.000000000, 0.000000000, 0.008973436, 0.01615218…
#> $ v_x <dbl> NA, NA, 0.3426396, 0.2664975, 0.1903553, 0.152284…
#> $ v_y <dbl> NA, NA, 0.3426396, 0.2664975, 0.1903553, 0.152284…
#> $ a_x <dbl> NA, NA, NA, -4.568528e+00, -3.426396e+00, -1.1421…
#> $ a_y <dbl> NA, NA, NA, -4.568528e+00, -3.426396e+00, -1.1421…
#> $ heading <dbl> NA, NA, 0.7853982, 0.7853982, 0.7853982, 0.785398…
#> $ heading_unwrapped <dbl> NA, NA, 0.7853982, 0.7853982, 0.7853982, 0.785398…
#> $ angular_speed <dbl> NA, NA, NA, 2.927346e-15, 0.000000e+00, 0.000000e…
#> $ angular_velocity <dbl> NA, NA, NA, 2.927346e-15, 0.000000e+00, 0.000000e…
#> $ angular_acceleration <dbl> NA, NA, NA, NA, -8.782038e-14, 0.000000e+00, 0.00…
#> $ angular_path_length <dbl> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, N…
